X-Cut Compact Diagonal Cutter 1000V-insulated 160mm – 73 06 160

Details

Knipex 73 06 160X-Cut Compact Diagonal Cutter 1000V-insulated 160mm

• Cuts finest strands as well as multi-core cables and piano wires.
• Powerful, light and universal.
• High cutting performance with minimum effort due to optimum coordination of the cutting edge angle and transmission ratio.
• Box-joint design: highest stability with low weight.
• Doubly supported joint axis for heavy duty.
• Large opening width for thicker cables.
• Cuts precisely, even through fine copper wires.
• Compact, low-weight construction.
• Universally usable, in the assembly, maintenance and production.
• 40% less force required compared with standard diagonal cutters of the same length.

• Cutting capacities soft wire (diameter): 4.8mm
• Cutting capacities medium hard wire (diameter): 3.8mm
• Cutting capacities hard wire (diameter): 2.7mm
• Cutting capacities piano wire (diameter): 2.2mm
• Cutting capacity copper cable, multiple-stranded: 12.0mm
• VDE tested
